SY42XR-129 Yagi Antenna
The SY42XR-129 Yagi Antenna (126–132 MHz) optimized for long-range, point-to-point VHF communication with high gain, signal clarity, and rugged performance in critical industrial and communication applications.
Description
The SY42XR-129 Yagi Antenna is designed for long-range, point-to-point VHF communication in critical industrial and communications applications. It operates within the 126-132 MHz frequency range. Its stacked Yagi design, combined with a screen reflector, enhances directional gain, signal clarity, and interference rejection, making it ideal for long-distance transmissions that require focused, high-efficiency communication.
Engineered for reliability in demanding environments, the SY42XR-129 offers exceptional signal stability, ensuring consistent, high-gain performance for applications that rely on robust and uninterrupted connectivity. Its durable construction is built to withstand harsh weather conditions, making it a trusted solution for air traffic control, remote monitoring, and industrial communication networks.
| General Specifications | |
|---|---|
| Model Name | SY42XR-129 |
| Part Number | 26563501 |
| Antenna Type | Yagi Antenna |
| Radiation Pattern | Directional |
| Compliances | RoHS, REACH |
| Markets | Military & Defence, Aviation & Air Traffic |
| Electrical Specifications | |
| Frequency (MHz) | 126-132 |
| Frequency Band | VHF |
| Gain - (dBi) | 14.5 |
| Polarization | Vertical or Horizontal |
| VSWR (Max) | 1.8:1 |
| Impedance (Ω) | 50 |
| Max Input Power (W) | 1000 |
| HPBW E-Plane (°) | 40 |
| HPBW H-Plane (°) | 40 |
| Mechanical Specifications | |
| Weight - lbs (kg) | 32 (14.5) |
| Ground Plane Diameter - in (mm) | 86 (2184) x 80 (2032) |
| Connector Type | N-Type (Female) |
| Number of Connectors | 1 |
| Mounting Specifications | |
| Mount Type | SY-M Mount Kit |
