D2214 Dipole Antenna
The D2214 Dipole Antenna is a rugged dual-output UHF antenna operating from 225-400 MHz, designed for secure, interference-free communications in military and air traffic control applications. It features independent dipoles with high isolation and omni-directional coverage, housed in a durable fiberglass radome.
Description
The D2214 Dipole Antenna is a rugged UHF antenna featuring dual independent dipoles within a single enclosure, designed for simultaneous multi-frequency operation with high isolation. Operating in the 225-400 MHz frequency range, this antenna provides omni-directional coverage with 2 dBi gain, delivering reliable, interference-free ground-to-air communication in military, defense, and FAA-regulated air traffic control applications.
Engineered to meet stringent military standards, the D2214’s robust fiberglass radome and proven construction ensure durability and performance in harsh environmental conditions, making it an essential component for mission-critical tactical communications and air traffic control networks.
| General Specifications | |
|---|---|
| Model Name | D2214 |
| Part Number | 98114701 |
| Antenna Type | Dipole Antenna |
| Radiation Pattern | Omni-Directional |
| Enclosure | Wound Fiberglass Radome |
| Colour | Olive Drab (RAL 6022) |
| NSN Number | 5985-01-287-7682 |
| Compliances | RoHS, REACH |
| Markets | Military & Defence, Aviation & Air Traffic |
| Electrical Specifications | |
| Frequency (MHz) | 225-400 |
| Frequency Band | UHF |
| Gain - (dBi) | 2 |
| Polarization | Vertical |
| VSWR (Max) | 2:1 |
| Impedance (Ω) | 50 |
| UHF Max Input Power (W) | 250 |
| Isolation - Min. (dB) | 30 |
| HPBW (°) | 75 |
| Mechanical Specifications | |
| Length - in (mm) | 85.4 (2169) |
| Weight - lbs (kg) | 10 (4.5) |
| Element Configuration | UHF |
| Number of Elements | 2 |
| Connector Type | N-Type (Female) |
| Number of Connectors | 2 |
| Environmental & Structural Specifications | |
| Operating Temperature - °F (°C) | -40 to 158 (-40 to 70) |
| Wind Loading Area - ft² (m²) | 1.21 (.11) |
| Wind Loading Area with ½" Ice - ft² (m²) | 1.87 (.17) |
| Bend Moment (ft-lbs) | 97.4 |
| Bend Moment with ½" Ice (ft-lbs) | 39.5 |
| Survival Rating No Ice - mph (kph) | 150 (241) |
| Mounting Specifications | |
| Mount Type | Mount A - Clamp Mount |
| Mast OD - in (mm) | 3 (76) |
Model Variants
- D2214-M2G Shipboard Antenna – Shipboard Model with Military Double Mast Clamp (225-400 MHz)
